| Cod. art.: | USW-FLEX-2.5G-8-POE |
| Marca: | Ubiquiti |
| EAN: | 0810084695968 |
| GPSR: | Maggiori dettagli |
| Disponibilità: | Disponibile Spedizione in 24/48 ore o RITIRA a Castelnuovo d/G |
| Peso: | 0,499 Kg |
| Quantità: |
Alimentatore NON incluso
Overview
Dimensions: 212.9 x 99.4 x 33.5 mm (8.4 x 3.9 x 1.3")
Port Layout:
2.5 GbE RJ45: 8 (All PoE++) (2.5G/1G/100M/10M)
10 GbE RJ45: 1 (PoE+++) (10G/5G/2.5G/1G/100M)
10G SFP+: 1 (10G/1G)
Max. PoE Output: Up to PoE++
Total PoE Availability:
- PoE+++ input: 76W
- PoE++ input: 46W
- PoE+ input: 16W
- 210W AC adapter input: 196W
Form Factor: Compact Desktop, wall, DIN, magnetic
Performance
Switching Capacity: 60 Gbps
Total Non-Blocking Throughput: 30 Gbps
Forwarding Rate: 45 Mpps
Supported VLANs: 256
MAC Address Table Size: 4,000
Layer 2 Features
STP & RSTP: ?
Egress Rate Limit: ?
Flow Control: ?
Storm Control: ?
Multicast & Broadcast Rate Limiting: ?
Port Isolation: ?
Port Mirroring: ?
Jumbo Frames: ?
Loop Protection: ?
Hardware
PoE Ports: PoE++: 8
Max. PoE Wattage per Port by PSE:
- PoE: 15.4W
- PoE+: 32W
- PoE++: 64W
Max. Power Consumption:
- 14W (Excluding PoE output) with PoE input
- 17W (Excluding PoE output) with AC adapter input
- 210W (Including PoE Output)
Power Method:
- (1) AC/DC adapter (Excluded)
- (1) PoE+++
Power Input Method:
- DC Input
- PoE
Supported Voltage Range: 50—57V DC/PoE
Management: Ethernet
Weight: 567 g (20 oz)
Enclosure Material: Polycarbonate
Mount Material: Polycarbonate
Ambient Operating Temperature:
-20 to 45° C (-4 to 113° F)
Ambient Operating Humidity: 10 to 90% noncondensing
NDAA Compliant: ?
Certifications: CE, FCC, IC
Software
Application Requirements:
UniFi Network
Version 9.0.114 and later
