| Prezzo: |
|
|---|---|
| Spese di trasporto: | A partire da € 15,74 IVA inclusaMaggiori dettagli |
| Cod. art.: | U-CABLE-C6-CMR |
| Marca: | Ubiquiti |
| GPSR: | Maggiori dettagli |
| Disponibilità: | Disponibile Spedizione in 24/48 ore o RITIRA a Castelnuovo d/G |
| Peso: | 16,000 Kg |
| Quantità: |
Mechanical
Box Dimensions: 474 x 346 x 458 mm (18.7 x 13.6 x 18")
Box Weight: 14.83 kg (32.69 lb)
Cable Length: 305 m (1000 ft)
Cable Color: White
Cable Type: Category 6
Shielding Type: UTP
Flame Rating: CMR
Conductor Wire Gauge: 23 AWG
Conductor Type: Solid Bare Copper
Jacket Material: PVC
Jacket Diameter: 6.0 ± 0.2 mm
Bend Radius: Min. 24 mm
Pulling Tension: Max. 110 N
Storage Temperature: -20 to 75°C (-4 to 167°F)
Installation Temperature: 0 to 60°C (32 to 140°F)
Operation Temperature: -20 to 60°C (-4 to 60°F)
Anti-Crosstalk Divider: Yes
Ripcord: Yes
Data Rate: 10/100/1000 Base-T
Reference Bandwith: Up to 600 MHz
Standards
Electrical Transmission:
- ANSI/TIA-568-C.2 (2009)
- ISO/IEC 11801 (Edition 2.2)
- IEC 61156-5 (Edition 2.1)
Flame Test: UL 1666 (CMR)
Material and Construction:
- UL 444
- CSA 22.2 NO.214
- EU Directive 2011/65/EU (RoHS2)
- EU Directive 2006/95/EC (LVD)
