Wireless Access Point BE3600 Dual-Band TP-LINK EAP725-Outdoor Wi-fi 7-1P RJ45 2.5G -MU-MIMO-802.3at POE IP66

Wireless
Standards and protocols:
- Wi-Fi 7
- IEEE 802.11 be/ax/ac/n/a 5 GHz
- IEEE 802.11 be/ax/n/b/g 2.4 GHz
WiFi speeds
- 5 GHz: 2882 Mbps (802.11be)
- 2.4 GHz: 688 Mbps (802.11be)

WiFi range:
3 Bedroom Houses
4× External Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

WiFi capacity:
High
- Dual-Band
- Allocate devices to different bands for optimal performance
2×2 MU-MIMO
- Simultaneously communicates with multiple MU-MIMO clients
OFDMA
- Simultaneously communicates with multiple clients
Airtime Fairness
- Improves network efficiency by limiting excessive occupation
DFS
- Access an extra band to reduce congestion
4 Streams
- Connect your devices to more bandwidth

Working modes:
- Router Mode
- Access Point Mode

Advanced features:
- Multi-Link Operation (MLO)
- 4K-QAM
- Multi-RUs
- EasyMesh-Compatible
- Works with Alexa and Google Assistant
- IoT Network

Wireless mode:
- Router Mode
- Access Point Mode

Sicurezza
Network security:
- SPI Firewall
- Access Control
- IP & MAC Binding
- Application Layer Gateway

HomeShield Security:
- Real-Time IoT Protection
- Malicious Site Blocker
- Intrusion Prevention System
- DDoS Attack Prevention
- Home Network Scanner

Guest network:
- 1× 5 GHz Guest Network
- 1× 2.4 GHz Guest Network

VPN server:
- OpenVPN Server
- PPTP VPN Server
- L2TP VPN Server
- WireGuard VPN Server

VPN client:
- Open VPN Client
- PPTP VPN Client
- L2TP VPN Client
- WireGuard VPN Client

WiFi encryption
- WPA
- WPA2
- WPA3
- WPA/WPA2-Enterprise (802.1x)

Hardware
Ethernet ports
- 1× 2.5 Gbps WAN
- 1× 2.5 Gbps LAN
- 3× 1 Gbps LAN

USB support:
- 1× USB 3.0
- Supported partition formats: NTFS, exFAT, HFS+, FAT32
- Supported functions: FTP Server, Media Server, Samba Server

Buttons:
- Power On/Off Button
- Wi-Fi On/Off Button
- LED Button
- WPS Button
- Reset Button

Power:
12 V ? 2 A (US)
12 V ? 1.5 A (EU)

Dimensions (W x D x H):
155 × 52.5 × 170 mm

Software
Protocols
- IPv4
- IPv6

Service kit: HomeShield
EasyMesh: Compatible with EasyMesh

Parental controls:
HomeShield Parental Controls
- Custom Profiles
- Professional Content Filter Library
- Family Time
- Bedtime
- Off Time
- Time Rewards
- Family Online Time Ranking
- Pause the Internet
- Weekly and Monthly Reports

WAN types:
- Dynamic IP
- Static IP
- PPPoE
- PPTP
- L2TP

Quality of service: QoS by Device

Cloud service:
- Auto Firmware Upgrade
- TP-Link ID
- DDNS

NAT forwarding:
- Port Forwarding
- Port Triggering
- DMZ
- UPnP

IPTV:
- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN

DHCP:
- Address Reservation
- DHCP Client List
- Server

DDNS:
- TP-Link
- NO-IP
- DynDNS

Management features:
- Tether App
- Webpage

Other
System requirements:
- Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
- Cable or DSL Modem (if needed)
- Subscription with an internet service provider (for internet access)

Certifications: CE, FCC, RoHS

Environment:
- Operating Temperature: 0?~40? (32?~104?)
- Operating Humidity: 10%~90% non-condensing

Test data
WiFi transmission power:
- KC: <23dBm (2.4GHz & 5.15GHz~5.825GHz)

WiFi reception sensitivity:
5 GHz:
- 11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm
- 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm
- 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm
- 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm
- 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm
- 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm
- 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm

2.4 GHz:
- 11g 6Mbps:-91dBm, 11a 54Mbps:-74dBm
- 11n HT20_MCS0:-90dBm, 11n HT20_MCS7:-73dBm
- 11n HT40_MCS0:-88dBm, 11n HT40_MCS7:-70dBm

Physical

Dimensions (W×D×H):
6.7 × 5.4 × 1.6 in (169 × 137.4 × 41.4 mm)

Package content:
- Wi-Fi Router Archer BE3600
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
