| Prezzo: |
|
|---|---|
| Spese di trasporto: | A partire da € 8,42 IVA inclusaMaggiori dettagli |
| Cod. art.: | UA-G3-PRO-W |
| Marca: | Ubiquiti |
| EAN: | 0810084697573 |
| GPSR: | Maggiori dettagli |
| Disponibilità: | Disponibile Spedizione in 48/72 ore lavorative |
| Peso: | 1,000 Kg |
| Quantità: |
Overview
Dimensions: 160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6")
Integrated Camera: ?
NFC Card & Keyfob Access: ?
PIN Access: ?
Apple/Google Wallet: ?
Mobile Unlock: ?
Two-Way Intercom & Doorbell Access: ?
NDAA Compliant: ?
UL 294 Level:
Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I
Weatherproofing: IP55
Weight: 136 g (4.8 oz)
Enclosure Material: Polycarbonate, glass
Mount Material: Aluminum alloy
Mounting:
- Wall, gang-box mount (Included)
- Angle mount, junction box (Optional)
Hardware
Indoor and Outdoor Use: Yes
Ambient Operating Temperature:
Device: -30 to 45° C (-22 to 113° F)
Display: -10 to 45° C (14 to 113° F)
Ambient Operating Humidity: 5 to 90% noncondensing
Networking Interface: (1) GbE RJ45 port
Connectivity:
- BLE 4.2
- NFC
Power Method:
- PoE
- UL 294 Power-limited Class 2 PSU
- UL 60950-1/62368-1 LPS/PS2 PSU
Max. Power Consumption: 6W
Supported Voltage Range: 48V DC
ESD/EMP Protection: Air: ±15kV, contact: ±8kV
Sensors: Proximity sensor
Display: 120 mm (4.7") diagonal
Touch Screen Technology: Capacitive touch
Display Luminance: 480 nits (Typical)
Screen Orientation: Portrait
Resolution: 1280 x 286 px
Microphone: ?
Speaker: ?
LEDs: R/G/B/W/Amber Learn More
Button: (1) Factory-reset
NFC Frequency: 13.56 MHz
NFC Read Range: < 30 mm (1.18'')
NFC Technology:
- ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)
- MIFARE Classic / MIFARE DESFIRE
- Sony FeliCa (ID only)
- NFC Forum tags T1T, T2T, T3T, T4T and T5T
- ECP 2.0
PoE Cabling Requirements: Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.
UL 294 Statement: Compliance with IEEE 802.3 specifications was
not verified as part of UL 294. The equipment is intended to comply
with the section of the National Electrical Code, ANSI/NFPA 70,
Article 725.121, Power Sources for Class 2 and Class 3
Circuits.
CAN/ULC-60839-11-1 Grade: Grade assignment: I
Certifications: CE, FCC, IC, SRRC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level:
UA-G3-Pro-W/UA-G3-Pro-B, V01
Software
Management Application: Access
